6. INPUT SOURCE SELECTOR SWICTH
(CH 1 TO 4)
Input source selector switch for channel 1-4:
Button pressed = phono/line (LED lights),
Button released = line (LED off)
7. CHANNEL HIGH CONTROL (CH1 TO 4)
Control HIGH adjusts the high range for
channel 1-4.
8. CHANNEL LOW CONTROL (CH1 TO 4)
Control LOW adjusts the bass range for
channel 1-4.
9. CHANNEL CUE (CH1 TO 4)
Cue button for monitoring channel 1-4 via
headphones.
10. LEVEL (CH1 TO 4)
Volume control for channel 1-4.
11. MIC LEVEL
Volume control for the microphone.
12. MIC ON/OFF
On/off switch for the microphone.
13. LEVEL METER
12-digit LED meter for the stereo master signal.
14. MASTER LEVEL
Volume control for the master output.
15. BOOTH LEVEL
Volume control for the booth output.
16. MIX (CUE)
Control MIX for the monitoring signal for the
headphones.
• Left stop position, CUE: the pre-fader level of
the input channel of which the CUE button is
pressed is monitored.
• Right stop position, PGM: the music program
currently playing is monitored ahead of the
master and booth output controls.
17. HEADPHONES LEVEL
Volume control for the headphones.
18. POWER
Power indicator LED.
All manuals and user guides at all-guides.com
19. SELECTOR SWITCH FOR THE HEADPHONES
DMR-400 REAR PANEL
20. POWER INPUT WITH FUSE HOLDER
21. ON/OFF
22. GROUND CLAMPING SCREW FOR
23. PHONO SENSITIVTY
24. PHONO/LINE SWITCH
25. INPUTS (CH1 TO 4)
26. MASTER OUTPUT
27. LINE LEVEL OUTPUT
28. BOOTH OUTPUT (XLR)
8
MONITORING MODE
• Button pressed (SPLIT): the pre-fader level
(mono) is on one side and the output signal
(mono) is on the other side of the headphones.
• Button released: a mixed signal of pre-fader
level and master signal is on both sides of the
headphones.
Used to plug in the supplied power cable.
Only replace the fuse when the device is
disconnected from mains. Only use fuses of the
same rating and power. The correct fuse value
is specified on the rear panel.
Power on/off.
TURNTABLES
Gain control for matching the input
amplification of phono inputs to line level
sources.
Switches between the phono inputs and
line inputs: Button released = phono, Button
pressed = Line.
Stereo inputs for channels 1-4. Connect devices
with line level outputs such as CD players to
inputs LINE 1-8, or turntables with magnetic
systems to inputs PH 1-4.
Balanced XLR output L/R for connecting
amplifiers or other units with line level input.
Stereo output (RCA) for connecting amplifiers
or other units with line level input.
Balanced XLR output L/R for connecting a
further amplifier, e.g. for the monitoring system
or PA application in a secondary room.
