17. SELECTOR SWITCH FOR THE HEADPHONES
MONITORING MODE
Button pressed (SPLIT): the prefader level
(mono) is on one side of the headphone and
the output signal (mono) is on the other side of
the headphones .
Button released: a mixed signal of prefader
level and master signal is on both sides of the
headphones.
18. INPUT SOURCE SELECTOR SWITCH FOR
CHANNEL 2:
Button pressed: Phono 2/line 3 (LED on)
Button released: Line 4 (LED off)
19. CHANNEL 2 HIGH CONTROL
Boosts and cuts frequencies in the high range
on channel 2.
20. CHANNEL 2 LOW CONTROL
Boosts and cuts frequencies in the low range on
channel 2.
21. CHANNEL 2 CUE
Press to monitor channel 2 via the headphone
output.
22. LEVEL
Volume level control for channel 2.
DMR-200 FRONT PANEL
23. XLR INPUT
Use this socket to connect a dynamic
microphone via XLR cable.
24. 6.3 MM JACK
Use this socket to connect your headphones.
DMR-200 REAR PANEL
25. ON/OFF
Turns the mixer power on or off.
26. POWER INPUT WITH FUSE HOLDER
Used to plug in the supplied power cable.
NOTE: Only replace the fuse when the device
is disconnected from mains. Only use fuses of
the same rating and power. The correct fuse
value is specified on the rear panel.
27. GROUND CLAMPING SCREW FOR
TURNTABLES
All manuals and user guides at all-guides.com
28. PHONO SENSITIVITY
29. PHONO / LINE SWITCH
30. CHANNEL 2 INPUTS
31. MASTER OUTPUT
32. LINE LEVEL OUTPUT
33. BOOTH OUTPUT (XLR)
34. BOOTH OUTPUT (PHONO)
35. RECORD OUTPUT
36. GROUND CLAMPING SCREW FOR
37. PHONO / LINE SWITCH
38. PHONO SENSITIVITY
39. CHANNEL 1 INPUTS
6
Gain control for matching the input
amplification of phono input 2 to line level
sources .
Switches the PH 2/LINE 3 jacks on channel 2
between phono and line input.
Button released: Phono
Button pressed: Line
Stereo phono inputs (RCA) for channel 2, used
for connecting line level equipment (LINE 3, 4)
or turntables (PH 2).
Balanced XLR output L/R for connecting
amplifiers or other units with line level input.
Stereo output (RCA) for connecting amplifiers
or other units with line level input .
Balanced XLR output L/R for monitoring.
Stereo output (RCA) for monitoring .
Stereo output (RCA) for connecting a recording
unit .
TURNTABLES
Switches the PH 1/LINE 1 jacks on channel 1
between phono and line input.
Button released: Phono
Button pressed: Line
Gain control for matching the input
amplification of phono input 1 to line level
sources.
Stereo phono inputs (RCA) for channel 1, used
for connecting line level equipment (LINE 1, 2)
or turntables (PH 1).
