Fitting Instructions - Read instructions carefully before fitting and follow them for correct use
IN8145
ULTI Bars - X4
FX4014
X8
FX4016
(RUBBER)
(M6)
ME0203
X8
ME0717
TOOLS REQUIRED
10MM X 1
EN - SAFETY AND PRODUCT INFORMATION
DE - SICHERHEITS- UND PRODUKTINFORMATIONEN
FR - INFORMATIONS DE SÉCURITÉ ET DU PRODUIT
NL - VEILIGHEIDS- EN PRODUCTINFORMATIE
ES - INFORMACIÓN DE SEGURIDAD Y DEL PRODUCTO
IT - INFORMAZIONI SULLA SICUREZZA E SUL PRODOTTO
?
This FITTING INSTRUCTION is the property of VAN GUARD ACCESSORIES LTD. and must not be used for
manufacturing purposes, copied nor communicated in any way to third parties without written
permission from VAN GUARD ACCESSORIES LTD.
IN8145_E
(CN:00183)
X24
FX4022
X8
FX4023
(M6X25)
X8
SV - SÄKERHETS- OCH PRODUKTINFORMATION
DA - SIKKERHEDS- OG PRODUKTINFORMATION
NO - SIKKERHETS- OG PRODUKTINFORMASJON
PL - INFORMACJE O BEZPIECZEŃSTWIE I PRODUKCIE
CS - INFORMACE O BEZPEČNOSTI A PRODUKTU
Customercare@van-guard.co.uk
UK +44 (0) 1392 368 351
X8
FX4042
X16
MA6018
(M6X16)
MA6166
ULTI Bar Trade
(Steel)
VG-051_02
X8
MA6065
X8
MA6167
X4
ULTI Bar+
Van Guard Accessories Ltd
Fair Oak Close, Exeter Airport Business Park,
Exeter, Devon, EX5 2UL
www.van-guard.co.uk
2
ME0034
X8
X4
(Aluminium)
IN8145 - PAGE 1 OF 6
