Fitting Instructions - Read instructions carefully before fitting and follow them for correct use
IN8221
ULTI Bars - X4
FX4010
X8
FX4016
(M6)
(M6)
ME0203
X8
ME0823
TOOLS REQUIRED
!
10MM X 1
This FITTING INSTRUCTION is the property of VAN GUARD ACCESSORIES LTD. and must not be used for
manufacturing purposes, copied nor communicated in any way to third parties without written
permission from VAN GUARD ACCESSORIES LTD.
IN8221_G
(CN:00114)
X16
FX4017
X8
FX4012
(M6)
X1
ME0824
X1
ME0826
X8
FX4042
X16
(M6X16)
(M6X16)
X1
ME0827
X1
GB. Tested to 80kg per bar. Maximum load is in accordance with the vehicle manufacturer's load bearing
capacity (refer to the vehicle handbook). Do not exceed this limit.
FR. Testé à 80 kg par barre. La charge maximale doit être conforme à la capacité de charge du constructeur de
véhicule (veuillez- vous référer au livret du véhicule). Ne dépassez pas cette limite.
DE. Geprüft bis 80kg pro bar. Die Maximallast steht im Einklang mit der angegebenen Ladekapazität des Fahrzeu-
gherstellers (diese finden Sie im Fahrzeughandbuch). Die Maximallast darf nicht überschritten werden.
DK. Testet til 80 kg pr. bar. Maksimal lasteevne afhænger af varevognproducents angivelser i varevognens
håndbog. Overskrid ikke denne grænse.
MAX
80KG
FX4126
X8
MA6081
X16
(M6)
ME0872
X4
AS3190
??
MAX
Van Guard Accessories Ltd
Fair Oak Close, Exeter Airport Business Park,
Exeter, Devon, EX5 2UL
www.van-guard.co.uk
MA6065
X8
X4
i
IN8221 - PAGE 1 OF 5
