dji MAVIC PRO Manuel De L'utilisateur page 54

Mavic Pro User Manual
Starting/Stopping the Motors
Starting the Motors
A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom
inner or outer corners to start the motors. Once the motors have started spinning, release both sticks
simultaneously.
Stopping the Motors
There are two methods to stop the motors.
Method 1: When Mavic Pro has landed, push the left stick down , then conduct the same CSC that was
used to start the motors, as described above
motors stop.
Method 2: When the aircraft has landed, push and hold the left stick down. The motors will stop after three
seconds.
Flight Test
Takeoff/Landing Procedures
1. Place the aircraft in an open, flat area with the battery level indicators facing towards you.
2. Turn on the remote controller and your mobile device, then turn on the Intelligent Flight Battery.
3. Launch the DJI GO app and enter the Camera page.
4. Wait until the Aircraft Indicators blink green. This means the Home Point is recorded and it is now safe
to fly. If they flash yellow, the Home Point has not been recorded.
5. Push the left stick up slowly to take off or use Auto Takeoff.
6. Shoot photos and videos using the DJI GO app.
7. To land, hover over a level surface and gently pull down on the left stick to descend.
8. After landing, execute the CSC command or hold the left stick at its lowest position until the motors
stop.
9. Turn off the Intelligent Flight Battery first, then the Remote Controller.
When the Aircraft Status Indicators blink yellow rapidly during flight, the aircraft has entered Failsafe
mode.
A low battery level warning is indicated by the Aircraft Status Indicators blinking red slowly or
rapidly during flight.
Watch our video tutorials for more flight information.
54
©
2016 DJI. All Rights Reserved.
OR
. Motors will stop immediately. Release both sticks once
OR
Method 1 Method 2
