Intimidator™ Wave 360 IRC QRG
Menu Map (cont.)
Main Level
System Info
IRC-6 (Infrared
Remote Control)
DMX Linking
Starting Address
Master/Slave
Connection
DMX Assignments
33CH
Channel
1
2
3
4
5
6
All manuals and user guides at all-guides.com
Programming Levels
Ver XX
Running Mode XXXXX
DMX Address XXX
The Intimidator™ Wave 360 IRC is compatible with the IRC-6 from Chauvet.
The following IRC-6 buttons are used with the Intimidator™ Wave 360 IRC :
·
<BLACKOUT>, <A>, <UV>, <W> - Turns LED on/off
·
<AUTO> , <0> thru <9> - Selects Auto program mode (1-16)
·
<SOUND> - Selects Sound mode
·
<STROBE> - Strobing (0–20 Hz)
·
<SPEED> - Auto program speed
·
<SENSITIVITY> - Sets sound sensitivity
·
<%> - Dimmer
·
<FADE> - Press once for Fade level, twice for Snap level
·
<+> and <-> - increase and decrease
·
<MANUAL> - Sets white color level
·
<R> - Sets red color level
·
<G> - Sets green color level
·
<B> - Sets blue color level
The Intimidator™ Wave 360 IRC works with a DMX controller. Information about
configuring the Intimidator™ Wave 360 IRC for DMX operation is in the User
Manual, which is
http://www.chauvetlighting.com/product-manuals-literature/. Information about
DMX is in the Chauvet DMX Primer, which is available from the Chauvet website
http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf.
To ensure full access to all channels in each DMX mode, the highest recommended
DMX address for this product is 480.
The Intimidator™ Wave 360 IRC works in Master/Slave mode. Information about
configuring this product for Master/Slave operation is in its User Manual, which is
available from the Chauvet website.
Function Value
Pan 000ó255 Pan 0–540°
Pan 16-bit 000ó255 Pan 16-bit
Pan Speed 000ó255 Pan Speed (decreasing speed)
000
Continuous Pan
001ó127 Continous pan rotating with increasing speed
Rotating
128ó255 Continous pan rotating with decreasing speed
Head 1 Tilt
000ó255 0–270°
Head 2 Tilt 000ó255 0–270°
Displays software version
Displays current operating mode
Displays current DMX address
available from
Percent/Setting
No function
6
EN
Description
the Chauvet website
