12 DIGITAL REVERB DR600
(2)
(1)
(8)
Thank you for showing your confidence in us by purchasing the
Behringer DIGITAL REVERB DR600. This ultimate effects pedal is
specifically designed to deliver 24-bit high-resolution stereo reverbs
comparable to state-of-the-art studio processors. Thanks to six
renowned modes and extensive parameter control for maximum
creativity you'll have plenty of cool sounds at your disposal for
every situation.
1. Controls
The LEVEL control adjusts the output level.
(1)
The TONE controlallows you to shape your overall sound.
(2)
The TIME control determines the rever time.
(3)
The MODE control lets you chose between six different
(4)
reverb sounds:
SPRING: Simulates classic spring reverberation.
PLATE: Simulates the sound of plat reverberation.
HALL: Very bright reverb that simulates the reflections of a
concert hall.
GATE: This effect snthetically cuts off reverberation after a period
of time.
ROOM: Clearly hear natural room acoustics.
MODULATE: By detuning the reverb tail it creates spacious,
almost choir-like reverb that reminds a little bit of a chorus effect.
The ON/BATT LED illuminates when the effect is activated. It also
(5)
serves as a battery level indicator.
Use the footswitch to activate/deactivate the effect.
(6)
Use the two 1/4" TS connectors IN A and IN B to plug in a stereo
(7)
input signal. For mono use just plug in IN A.
The two 1/4" TS connectors OUT A and OUT B send the signal to
(8)
your amp. Use both connectors if you want to achieve full stereo
effect. For mono use just plug in OUT A.
(5)
(4)
(3)
(7)
(6)
