entitlements will no longer apply.
Handle the uni 14_/22_/20_95RF
and accessories with care; do
not disassemble or modify them,
do not allow children to play with
them and prevent frail individu-
als from using the product with-
out supervision.
The product may not be used
with a medical device or be in-
stalled in a medical device.
The product may not be used in
an environment in which flam-
mable or explosive gases or va-
pours (e.g. anaesthetics) are
likely to occur.
The product may not be used to
raise and lower loads.
Only use spare parts that have
been produced or approved
by Swissflex. Only these parts
guarantee adequate safety.
The slat base may only be used
with the power supply provided.
22
Operating instructions
All manuals and user guides at all-guides.com
Initial setup «Touch»
Place the batteries into the radio remote control
Remove the cover from the battery compartment
(21) on the back of the radio remote control. Place 3
AAA-batteries (22) into the compartment, paying at-
tention to the +/- markings. Close the compartment
cover again. The maximum range of the radio remote
control is 15 metres.
Teaching-in the radio remote control (already
taught-in in the factory)
1. Remove the radio remote control's battery cover on
2. Insert / check the batteries (3 x AAA).
3. Activate the teach-in button (30) on the switching
4. A small red button is located above the batteries in
5. Press the button; a blue LED will start flashing.
6. Hold the button down until the blue LED is
Bluetooth
1. Download the standard „Swissflex" app from the re-
2. Install the standard „Swissflex" app onto your
3. Installation / Initial setup, see manual of the Blue-
Synchro function (with sync cable)
When two uni 14_/22_/20_95RF are linked together
with a sync cable (connection jack (23)), the synchro
function (17) is required. By pressing and holding down
the button (17), the synchro function is activated/de-
activated. When pressing the travel button (6-7), the
control systems synchronise and then move in the con-
firmed direction of travel. After successful activation,
the button glows blue continuously. After successful
deactivation, the button appears white. After plugging
in the sync cable, carry out a reset as follows:
• Press down the 'Memory/Save' button (18) for 3 se-
• The M1-M4 buttons will first light up blue and then
• The LCD backlighting system will flash white once
• Immediately press down the synchro button (17)
• If the entire backlighting system flashes white twice,
The internal meter readings for the individual motors
the back of the device.
power supply (press 2 x).
the battery compartment (21).
permanently illuminated; this means that pairing
has been completed.
®
levant platform for Android (Google play) or Apple
iOs (App Store).
Smartphone / Tablet PC.
tooth RF-Gateway.
conds.
switch to white again.
after several seconds.
and keep it pressed down. The control systems po-
wer down.
you can release the synchro button (17).
