EIS 65.100-1
01/22 Rev. I
index:
English Instruction Sheet ............................................................ pages ............ 1-5
Repair Parts Sheet ...................................................................... pages .......... 7-14
Française Notice d'Emploi ......................................................... pages ........ 15-19
Deutsche Bedienungsanleitung .................................................. Seiten ....... 20-24
Italiano Manuale Istruzioni .......................................................... pagine ....... 25-29
Español Instrucciones ................................................................ páginas ..... 30-34
Nederlandse Gebruikershandleiding ...................................... blz. ........... 35-39
Русская инструкция .................................................................
1.0 IMPORTANT RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage.
Shipping damage is not covered by warranty. If
shipping damage is found notify carrier at once. The
carrier is responsible for all repair and replacement
costs resulting from damage in shipment.
safety first
Read all instructions, warnings and cautions carefully.
Follow all safety precautions to avoid personal
injury or property damage during system operation.
Enerpac cannot be responsible for damage or
injury resulting from unsafe use of product, lack of
maintenance or incorrect product and/or system
operation. Contact Enerpac when in doubt as to the
safety precautions and applications.
TO PROTECT YOUR WARRANTY, USE ONLY
ENERPAC HYDRAULIC OIL.
2.0 PRODUCT DESCRIPTION
Enerpac BHP-series puller sets consist basically of
a handpump, single-acting cylinder, gauge, gauge
adaptor, hose, couplers and specific tools and
attachments. The pullers are designed for installing
and removing all press fitted and heat fitted parts
such as gears, pulleys, wheels, bearings, sleeves,
sprockets, pins and other stubborn parts.
The Enerpac BHP-series puller sets are available as:
Grip Puller Sets (see paragraph 2.1), Cross-Bearing
Puller Sets (see paragraph 2.2) and Multi-Purpose
Puller Sets (see paragraph 2.3).
All manuals and user guides at all-guides.com
Instruction and
Repair Parts Sheet
BHP Puller Sets
and Attachments
Puller set attachments are additional parts to
increase on-the-job flexibility further with the use
of grip pullers and cross-bearing pullers. See tables
D and E on the pages 13 and 14 for the individual
components of puller set attachments.
2.1 Grip Puller Sets
The grip puller sets BHP-152, BHP-251G, BHP-
351G and BHP-551G can be used to remove and
install gears, bearings, pulleys and similar parts. See
Illustration  3 on page
with a double crosshead (2 grip arms) or a triple
cross head (3 grip arms). For individual parts see
table A on page 9.
2.2 Cross Bearing Puller Sets
The cross bearing puller sets BHP-162, BHP-261G,
BHP-361G and BHP-561G can be used to remove
and install gears, pulleys, sleeves and bushings.
These pullers can also be used as bearing cup
pullers (internal grip pullers) as shown in Illustration 4
on page  4 or as bearing pullers as shown in
Illustration 5 on page 4.
In situations where clearance prevents a direct
application of grip puller arms, it is possible to use the
puller in combination with bearing puller attachment
as shown in Illustration 6 on page 5. Bearing puller
attachments have wedge shaped edges to place the
puller behind the hard to reach the gear or bearing.
See table B on page 11 for individual components.
1
. .. 40-44
страница
4.
Grip pullers can be used

Publicité

loading

Sommaire des Matières pour Enerpac BHP
