STEP 20
Folding the MoJack PRO
• Pull locking pin out to unlock.
• Raise the Tower out of the Base by pulling up on
the
Grip Handle and then lower the Tower.
• The tower will be securely locked in place when the
locking pin retracts.
THE MOJACK PRO IS NOW READY FOR STORAGE OR TRANSPORT.
STEP 21
Raising the MoJack PRO with a power drill (optional)
• The MoJack PRO can be raised or lowered by using a
variable speed corded drill (7 amp minimum) or variable
speed cordless drill (18V minimum).
• The drill will require a 7/16" socket (not provided).
• Remove the Winch Handle by removing the
Nylock Nut and Winch Handle Washer.
Operator must have a firm grip on the drill before
raising or lowering the Lift Arm.
• Firmly place the 7/16" socket on the Drill Reducer.
Rotate the drill in reverse (counterclockwise) to raise
the Lift Arm and rotate the drill forward (clockwise) to
lower the Lift Arm.
• Ratchet Release Handle and Grip Handle must be
squeezed together when lowering the Lift Arm.
• Follow all other operating instructions while using the drill attachment.
• Replace the Winch Handle for future use.
MoJack PRO Lift
Operating Instructions
17
Lift Tower
out of Base
Drill Reducer
7/16" Socket
Tower Locking
Pin
(unlocked position)
Tower Locking
Pin
(locked position)
Remove Winch Handle
