replaCe upper tank
1.6 Position bottom of
tank onto cleaner.
1.7 Push top of tank
and tank handle while
supporting back of
cleaner with other hand.
1.8 Push up on handle
to latch it to cleaner.
Check tank to make
sure it is secure.
attaCh hose/Cord hook
1.9 Snap hook onto
cleaner.
attaCh tool CaddY
(for storage on cleaner)
(Available on select models only)
1.10 Insert tabs.
1.11 Slide caddy down. Notch (B) rests on hook (C).
IMPORTANT
Tool caddy is removable for storage on wall or
in closet.
store hose
1.12 Start.
1.13 Wrap.
1.14 Finish. Use clips
(D) to secure hose and
solution tube (E and in-
set).
1.13
Actual model may vary from images shown.
All manuals and user guides at all-guides.com
1.6
1.9
1.12
1.14
D
E
E
D
6
1.7
1.10
1.8
1.11
C
b
store tools
1.15 Store Tools on
back side of cleaner as
shown.
1.15
