Carton Contents
1.1
b
A
A. Cleaner
B. Upper Handle
C. Handle Bolts and Nuts (Three nuts may be in
bag but only two or need for assembly. Bolts and
nuts located in bag with hose)
D. Hose/Cord Hook
E. SpinScrub ® Brush Assembly
Remove all parts from carton and identify each
item shown.
Make sure all parts are located before disposing of
packing materials.
attaCh handle
1.2 Remove tank.
1.3 Position cord protector.
1.4 Slide handle down.
1.5 Insert bolts and attach nuts. Tighten with
screwdriver.
All manuals and user guides at all-guides.com
1. Cleaner asseMblY
Carpet
Upholstery
Cleaner
C
D
E
5
Bare
Pre-
floor
Cleaner
cleaner
H
F
F. Hose/Tool Caddy*
G Hose
H Stair/Upholstery Nozzle
I. SpinScrub ® Hand Tool*
*Available on select models only. Accessories not
included with your model may be purchased
separately by visiting hoover.com.
NOTE: Phillips screwdriver needed for assembly.
1.2
1.4
Actual model may vary from images shown.
G
I
1.3
Cord Protector
-V2
1.5
