FINS
SETTING UP THE FINS :
Because of the assymetrical profile, the fins are color coded (red and green) to facilitate
their assembly. The matching color is also present inside the fin holes on all of our twin-tip
boards. As a result, mounting the fins is really easy: red on red, green on green. The box
part can be mounted in either orientation.
Make sure the green fins are fitted into the green
holes of the board. Same goes for the red fins.
1
Fit the box onto the upper part of the fin.
3
In case you break one of the fins, you can always fit
a standard twin-tip fin by placing washers between
the board and the screws. You can also use other
leash bars available on the market.
SETTING UP A LEASH :
A notch has been created on the box so you can
mount a leash board if you need to.
To set up your board only use the F-ONE straplocks, pads and screws.
www.f-onekites.com
All manuals and user guides at all-guides.com
Insert the fins into the holes of the board.
2
Screw on the fins.
4
