3） Take-up
EN
Press the button on the
Put the buoyancy line
right side of the
into the straightener
straightener to open the
and close the lid of the
straightener cover.
straightener.
Specifications
Size
Weight
Maximum storage cable length
Precautions
1. If you encounter a blasting line, you should stop retracting and unwinding
the line immediately and rearrange the buoyancy line before continuing.
2. Before use, check whether the O-ring seal on the buoyancy line plug is
dropped or damaged. If it is missing or damaged, please replace it in time.
3. During the winding process, please pay attention to fixing the manual
winder to prevent it falling and hurting people or damaging the machine.
4. The manual winder supports an IP65 waterproof level. Please do not put
the manual winder directly into the water or splash liquid on it. If it is
damaged by water, it will not be covered by the warranty.
Support
If you have any questions or technical issues, send an email to the aftersales services of
Chasing or contact us on the official website.
Aftersales support on the official website: https://www.chasing.com/ >> Contact us >>
Aftersales service email addresses: support01@chasing-innovation.com for Europe,
support02@chasing-innovation.com for Asia and Oceania,
and support03@chasing-innovation.com for South America,
North America, and Africa.
This guide may be updated without notice.
Visit the Chasing official website for the latest version: https://www.chasing.com
05
Install the manual handle
and start to take up the
wire manually.
2 96x 1 89 x2 79 m m
2 .5 kg
2 00m
Online Customer Support >>Click here
手动绕线器用户手册
V1.0
手动绕线器（Reel）共使用14颗专用定制不锈钢轴承，采用高精度铝合金同步带传
动和优质不锈钢往复丝杆排线防缠绕技术。IP65防水防尘等级，最大可搭载200米
线缆。整体结构简单，性能可靠，赋予您更多操作乐趣。
1
2
3
1. 提手
2. 把手接口
3. 可拆卸手把
4. 3米连接线接插口
5. 3米连接线(连接手柄和手动绕线器)
安装与连接
1.将3米连接线分别连接到手动绕线器和手柄并锁紧螺母。
2.将手动绕线器上的浮力线连接到到潜航器上并拧紧螺母。
3.预留合适长度，将线缆头部的挂扣挂在潜航器尾部挂扣支架上并收紧。
1
4
5
3
2
CN
