2
Installation
Maximum feeding width of 13" (33 cm)
Operation
Care and Cleaning / Storage
Laminates up to a maximum thickness of 0.02" (0.4 mm)
Warning / Safety Instructions
Accepts pouches up to a max. thickness of 3-4 mil (80-100 microns)
Troubleshooting
Service Center
Voltage: 120v~60Hz / 3.3A
One Year Limited Warranty
INSTALLATION
To reduce the risk of electric shock, if the machine has a polarized ETL approved plug (one blade is
wider than the other), this plug will fit in a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper
outlet. Please do not change the plug in any way. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard.
As pictured, attach the cooling holders to the dedicated slots located in the back section of the laminator.
There are 4 slots, 2 for each holder. Each holder will hook onto the lower part of the outlet on both the
left and right sides.
OPERATION
This machine can be used with cold or warm laminating films. The items being laminated can be pictures,
cards, documents, paper, etc. but must be no thicker than 0.02" (0.4 mm).
NO CARRIER SHEET IN REQUIRED. Only use pouches intended for laminators. Make sure item in
laminating pouch is evenly inserted. For smaller items, do not use too large a pouch since this may
cause poor laminating quality and create jams. Do not laminate wet items. Laminating damp/moist
documents will result in poor laminate quality.
To avoid creasing, DO NOT insert the item with the "open side" of the laminating
pouch first. Be sure to follow the guidelines on the feed guider to properly insert the
item in to the entry. Be sure to insert with the closed (sealed) edge of the laminating
pouch first.
3
CONTINUED NEXT PAGE
