8
pre setup
9
pre time
10
hold torun
11
indic light
12
cycle servi
13
setup servi
14
LED TYPE
15
elect time
16
boost setup
17
encod setup
18
motor setup
Defines pre-flashing modes of FLASH, IND/ELEC
and LED outputs if FLASH SETUP = 0/1
0 = pre-flashing before each opening manoeuvre
1 = pre-flashing before each closing manoeuvre
2 = pre-flashing before each opening manoeuvre
ATTENTION !
pre-flashes on opening only; LED output (red light)
pre-flashes on closing only
Defines the duration of the pre-flashing
tP.r.
ATTENTION !
performed
Enables the "man present" function on SBS, OPEN
and CLOSE inputs
de.a.
ATTENTION !
the operation of the remote controls is inhibited
Defines the behaviour of the IND/ELEC and LED
outputs (barrier lights)
5 = MODE 1
• barrier closed, LED output active (red LEDs)
• barrier open, IND/ELEC (green LEDs) and
LEDs (red LEDs) outputs not active
• during opening, IND/ELEC output flashing
(green LEDs)
• during closing, LED output flashing
(red LEDs)
IN.D.
• barrier stopped in intermediate position,
LED flashing (red LEDs)
6 = MODE 2
• barrier closed, LED output active (red LEDs)
• barrier open, IND/ELEC outputs active
(green LEDs)
• during opening, IND/ELEC output flashing
(green LEDs)
• during closing, LED output flashing (red LEDs)
• barrier in intermediate position, LED flashing
(red LEDs)
Specifies the number of manoeuvres before the
maintenance request signal (if 0, the function is
disabled).
se.r.
ATTENTION !
output; if closed, it flashes continuously.
Enable maintenance request signalling
se.f.
0 = deactivated
1 = active
Set to 0 if the old CTLIGHT2 module is used
If FLASH SETUP = 3; activation time (in seconds) of
the electric lock connected to the IND/ELEC output
EL.T.
If FLASH SETUP = 4; demagnetisation time
(in seconds) of the magnetic lock connected to the
IND/ELEC output
If active, maximum acceleration at start-up
ST.P.
0 = deactivated
1 = active
Displays the encoder type in use
En.C.
0 = virtual encoder
1 = physical encoder
Defines the type of automation on which the control
DE.F.
unit is installed and resets the default values.
1 = 3m barrier FAST
iND/ELEC output (green light)
if set to 0, no pre-flashing is
when this function is enabled,
signalling is via the FLASH
0 0 2
0 0 20
0 0 1
6 5 6
x 1000
10 0 200
0 0 1
1 0 1
4 1 10
0 0 1
1 1 1
1 1 1
EN
s
cicli
s
