EN
6.6 - Display during normal operation
6.6.1 - Status messages on the display
After powering up the equipment, the display shows the status of the system. The following table lists the possible states.
See the second column for comparison with the previous CT10224 electronic board.
CT10324
LEARN TO DO
READY
ìOPEN ING
CLOs ING
STOP OPEN
STOP CLOSE
FOTO1
FOTO2
ALIGN MENT
OPEN
TIME CLOSE
ERROR LEARN
LEARN OPEN1
LEARN CLOS1
SLOW OPEN2
SLOW CLOS2
6.6.2 - Error reporting
This section lists some malfunctions that may occur.
KEY TO MAIN CONTROL FLASHING
LIGHT AND KEY LEDS CONTROL UNIT
2 lampeggi veloci + pausa + 1 lampeggio
4 lampeggi veloci + pausa, 3 volte
2 lampeggi veloci + pausa, 3 volte
5 lampeggi veloci + pausa, 3 volte
3 lampeggi veloci + pausa, 3 volte
6 lampeggi veloci + pausa, 3 volte
6.6.3 - Malfunctions
This section lists some malfunctions that may occur.
SURGE OVERLOAD ALARM
OVER LOAD1
SAFETY EDGE ALARM
EDGE
ENCODER ALARM
enc error
PHOTOCELL ALARM/SAFETY EDGE
FOTO TEST
14
OLD CT10224 MEANING
Learning not done
--
Barrier closed or switch-on after shutdown
OP
Barrier opening
CL
Barrier closing
SO
Barrier stopped during opening
SC
Barrier stopped during closure
F1
Photocell 1 tripped
F2
Photocell 2 tripped
ALI
Re-alignment procedure
oP
Barrier open without automatic reclosure
The barrier has reached the open position and automatic re-closure is active; the
-tC
flashing dash indicates that the countdown is active. During the last 10", the remaining
seconds until re-closure are displayed.
L--
Learning stopped due to activation of safety device or motor reverse
LOP
Learning the opening stroke
LCL
Learning the closing stroke
SOP
Point of M1 deceleration on opening (only during stroke learning)
SCL
Point of M1 deceleration on closing (only during stroke learning)
EVENT
autolearning
obstacle M1
photo 1 / photo 2
safety edge
phototest error
FLASH/IND-LED error
The motor's current drawdown has increased very quickly
1. The barrier has hit an obstacle (M1)
2. Excessive friction in rod movement
The control unit has received a signal from the safety edge
1. The safety edge is active
2. The safety edge is not connected correctly or is faulty
Encoder do not respond
1. Check the encoder connection
2. Check that the encoder is operating correctly
Phototest fail outcome
1. Check photocell connections
2. Check that the photocells are operating correctly
DESCRIPTION
During the programming phase
Motor 1 obstacle detected
Photocell 1 tripped / Photocell 2 tripped
Safety edge tripped
Phototest error detected
Line overload flashing light, gate open/electric lock indicator light,
LED lights
