Napoleon FRANKLIN NEFE30-3020RK Manuel D'installation

FRANKLIN™ ELECTRIC FIREPLACE MEDIA CONSOLE
Model
NEFE30-3020RK
NEFB30H
NEFE30-3020RK
Overview
Media Console
This NEFP30-3020RK media console comes with two separate boxes, while assembly is required. The media console
15 lbs (6.8 kg)
after assembly is demonstrated below:
15 lbs (6.8 kg)
15 lbs (6.8 kg)
30 lbs (13.6 kg)
15 lbs (6.8 kg)
30 lbs (13.6 kg)
NEFB30H
Electric appliance
Dimensions
Product information provided is not complete and is subject to change without notice. Please consult the installation manual for
the most up to date installation information.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 0G8 Canada
BTU Width
N/A 70
5,000 30
NEFE30-3020RK
Media Console
NEFB30H
Electric appliance
70"
70"
1778mm
1778mm
Height Depth
35 20 13/16
20 5/16 7 3/4
Recommended Max. TV Size: 75"
Recommended Max. TV Size: 75"
35"
889mm
35"
889mm
1(866)820-8686
Viewing Area
N/A
27 15/16 X 15 3/16
120 lbs (54.5 kg)
120 lbs (54.5 kg)
19"
483mm
19"
483mm
20 13/16"
20 13/16"
528mm
528mm
W415-3081 / 06.11.21
