Input for connection to MASTER instrument
1
via C2050 cable
2
WiFi LED
3

POWER LED

4

STATUS LED

5
Indication of LED status

4.1. DESCRIPTION OF THE INSTRUMENT

Fig. 1 Description of the instrument
10
4.2. DESCRIPTION OF MEASURING LEADS
26
6
Input terminal C1
7
Input terminal C2
8
Input terminal P1
9
Input terminal P2
Plug cable for connection to mains supply
EQUITEST
