GAS 210 ECO PRO
3. Control

3.1 Control panel

fig. 01 Control panel
1 = Display
2 = [Menu] key
3 = [Service engineers] key
4 = [Escape] or [reset] key
114500-090211
The boiler's control panel contains four function keys, a menu key,
a chimney-sweeping key, an on/off switch and a display.
1
2
3
4 5 6
5 = [Central heating temperature] or [-] key
6 = [+] key
7 = [enter] key or [Service] indicator
8 = On/off switch
The display has four positions and several symbols and provides
information about the operating status of the boiler and any faults.
Numbers, dots and/or letters may be shown.
The symbols above the function keys indicate what the function of
the relevant keys is at that moment.
If no key is pressed for three minutes, the display lighting switches
off and only the  and  symbols are displayed. Press any key;
the current boiler status and the current operating code appear on
the display. This is always displayed in the event of a fault.
3.1.1 Start-up the boiler
1. First follow the guidelines that your installer supplied for the
entire installation. If not available: follow the instructions
below.
2. Check the water pressure in the installation (min. 0.8 bar). Fill
up when necessary.
3. Open the main gas cock.
4. Put the boiler control to heat demand.
5. Start the circulation pump.
6. Switch on the electrical supply to the boiler and the on/off switch
on the instrument panel; the Gas 210 ECO PRO will perform
the start-up program.
The following appear successively in the display:
- a short display test, whereby all of the display's segments are
visible;
fXx software version alternating with 1;
pXx parameter version;
8
Bar
7
114492LTAL21H008a
