Introduction
Congratulations on the purchase of
your new appliance. You have selected a
high-quality product. The operating instruc-
tions are part of this product. They contain
important information about safety, usage
and disposal. Before using the product,
please familiarise yourself with all operating
and safety instructions. Use the product
only as described and for the specified
range of applications. Please also pass
these operating instructions on to any
future owner.
Intended use
The appliance is designed for planing
workpieces such as beams or planks that
are firmly held in place. The appliance is
also suitable for chamfering edges and for
grooving. Any other uses of or modifica-
tions to the appliance are deemed to be
improper usage and may result in serious
physical injury. The manufacturer accepts
no responsibility for damage(s) attributable
to misuse. This appliance is not intended
for commercial use.
Features
Safety lock-out
ON/OFF switch
Chip ejector (optionally right/left)
Belt cover
Battery display LED
Battery charge level button
Release button for the battery pack
Screws for belt cover
Fastening screw for the rip fence/
fold depth stop
Plane sole
|
2
GB / IE
V grooves
Marking for cut depth scale
Cut depth scale
Dial for setting the cut depth
(additional handle)
Adapter for external extraction
Parking shoe
Cutter block
Clamping element
Fastening screw for the planing blade
Planing blade
Tensioning plate groove
20a
Hex screws
Lateral cutter block guard
Drive belt
Large belt wheel
Small belt wheel
Open-ended spanner
Hex key
Fold depth stop (not supplied)
Rip fence (not supplied)
28a
Battery pack*
High-speed charger*
Red charge control LED
Green charge control LED
Ready2Connect LED
v
Accessory compartment
b
Package contents
1 20V cordless planer
1 hex key (see fig. G+H)
1 open-ended spanner (see fig. G+H)
1 adapter for external extraction
1 carrying case
1 set of operating instructions
