ILDA console mode: ILDA signal input, output ILDA effect.
Effects library: Each effect library is stored as a sequence on the motherboard, they are:
1. Geometric sequence (Gypsophalange filter);
2. Wedding theme sequence;
3. Christmas theme sequence;
4. Beam sequence (no filter);
5. Geometric sequence (Galaxy Nebula);
6. 3D sequence (3D filter);
7. Point circle sequence (dot circle filter);
8. Long virtual point sequence (long virtual point filter);
LED DISPLAY INSTRUCTION:
{INTR}{DMX}{APP}{SET}{SND}{SEL} for status identification.
•
{INTR} Indicates that the fixture is using the built-in effect. When the status flag is lit (INTR} alone, it is the
built-in effect play mode.
•
{DMX} indicates that the fixture is controlled by the DMX signal. The status flag is only bright (DMX) for the
standard DMX control mode
•
{INTR} {DMX} is a simple DMX mode that calls the built-in scenario via DMX signals.
•
{SET} indicates that the fixture is in the system setup state.
•
{SND} indicates that the motion of the pattern is controlled by the sound when the fixture is in the built-in
mode.
•
{SEL} In the set state, the indicator is lit to indicate that the current setting option is enabled.
{INTR} the state of the digital display section
•
{AL} indicates the mix mode in the built-in mode (the scene play is extracted from each sequence).
•
{P ###} Indicates the scene playback mode when the built-in mode is displayed. The displayed value is the
scene number.
•
{SE ##} indicates the sequence playback mode when the built-in mode is displayed, and the displayed value
is the sequence number.
{DMX} the digital display part state.
{INTR} + {DMX}the digital display part state.
•
{A ###} Indicates the DMX address code for the fixture.
{SET} the digital display part state.
•
{SE ##} Indicates whether the digital display sequence is selected when the mixed mode of the built-in mode
is used.
(Note: {SEL} status flag indicates whether the sequence is selected.)
•
{DR- ||} indicates the X mirror setting.
•
{DR- =} represents the Y mirror setting.
•
{DR- = ||} represents XY offset.
•
{x ###} represents the X projection amplitude, the digital part is the full scale percentage value
(Note: {SEL} can be adjusted through the button on the board).
•
{y ###} denotes the Y projection amplitude (Note: same as above).
•
{r0FF} Indicates whether or not the remote control function is turned off.
The virtual remote control of the mobile phone APP is the same as that described in the previous section.
Extinguished: After a few hours of no operation, the digital part of the display will go out (Note: the screen func-
tion with the specific model, some models do not have the function)
Please operate the remote control within a distance of 6m and 30° between the remote and the appliance. Aim
the remote at the sensor. Remove all obstacles between the remote and the sensor.
The remote control might not work properly if the sensor is exposed to strong sunshine.
If the remote control doesn't work properly, please check the batteries.
6
