4
Replace the front sleeve.
6
Screw rivet nut into the mandrel. Adjust fixing screw for optimal fastening distance and Position the rivet
nut into the workpiece.
7
Squeeze handles & screw out the mandrel
from the rivet nut.
•Explosion drawing
Nose
Front Sleeve
piece
Scell-it UK LTD Beacon Industrial Estate Weston road - Stafford ST18 ODG - Tel. : 01785 246539 - sales@scellit.co.uk - www.scellit.com
5
B
Open the tool handles.
Mandrel
T E C H N I C A L S E R V I C E
EN
EN
FR
PL
Pull Bar
3
N100P / User manual
