Extend the leveling legs from the base of the dishwasher by the length
3.
indicated in the following chart. Take into account any built-up flooring
which may need to be added to the rear foot adjustment.
NOTES:
If the floor was built up in for the front of the dishwasher, account
•
for this difference when adjusting the rear leveling legs.
Final leveling leg adjustments will be made following installation
•
into the opening.
a
Opening Height
34"
1/4
34
"
1/2
34
"
14
3/4
34
"
35"
INSTALL 90° ELBOW
Wrap the 90° elbow with thread seal tape.
1.
NOTES:
Do not use plumber's putty.
•
To avoid damaging the water valve bracket and/or fitting, do not
•
over tighten the elbow.
Leveling Leg Adjustment
Front Legs
Back Legs
0
0
1/4
"
1/2
"
3/4
"
a
Adjust Leveling
Legs to Installation
Height
0
1/4
"
1/2
"
3/4
"
1"
