New Construction Installation
5 Connect Wires and Install Knockout Plate
• Run 120VAC electrical wiring to the installation location.
• Use proper UL-approved connectors to secure wiring to the Knockout Plate provided in Parts Bag.
• Connect wires as shown in wiring diagram.
• Do not use a dimmer switch to operate the light.
Fan
LIGHT
SWITCH
NIGHT LIGHT
SWITCH
FAN
SWITCH
LINE WHT
IN
GRD
BLACK
WHITE
BLUE
LIGHT
NIGHT LIGHT
FAN
MULTI CONTROL
(purchase separately)
Attach cable clamp to Knockout
1
Plate. Knockout Plate mounts to
outside of Housing and may be
oriented as desired.
Light
2
Connect wires
BLK
RED
WHT
BLK
BLK
WHT
GRD
SWITCH BOX
RED
GROUND
(green or bare)
SWITCH BOX
120 VAC
LINE IN
WHT
BLU
LIGHT
RED
NIGHT
WHT
LIGHT
BLK WHT
FAN
UNIT
LIGHT
RECEPTACLE
WIRES
FAN
RECEPTACLE
LIGHT
RECEPTACLE
KNOCKOUT
PLATE
FAN
RECEPTACLE
WIRES
RB80LC  RB110LC Installation Guide

3
4
Screw from
Parts Bag
