How to use
1 Switch on the unit
Load battery, the unit run self-test by 'BiBi' to anouce test passed. Press POWER key for 3 seconds, the LED
indicator on the receiver will flash once, then speaker will beep specially for 3 seconds. The unit will enter standby
mode.
2 Trun on the unit
Switch the 'Power' key on the right side of the unit to 'ON', 9 LED indicators flashes in turn; speaker sound for 2" to
announce unit starts.
3 Adjust the volume
In standby mode, press 'V' button to adjust the volume, there are 6 levels including mute, initial setting is level
6 - the max volume.
4 Select the tone
The sound tone for paired transmitter and receiver is sychronized to be same. i.e. the alert tone for receiver is
decided by the tone set on the paired transmitter. There are 8 cycle optional tones for choice for casting the
fishing line, and only 1 tone for winding the fishing line.
5 Alarm mode selection
In standby mode, press 'VB' button in the middle of the reciver, to select alarm mode from below three:
light+sound, light+sound+vibration or light +vibration.
6 Function for 'M' key
In standby mode, press "M" key will indicate the last recorded alert received from transmitter.
7 How to indentify Casting or winding fishing line
The LED indicator and alert sound will show you fishing line on transmitter is casting or winding. In case any color
LED flashes or the alert sound is one of the 8 tones for casting from transmitter, then you can judge that the fishing
line is casting; in case the white LED indicator below the color LED indicator is flashing and the sound tone is
winding tone, then you may judge that the fishing line is winding.
8 Pair transmitter to your reciever
In standby mode, you may choose one channel to pair a transmitter. First please choose the channel you need
to pair, press 'S' key to choose the 1st channel and the red indictor will light up. Press 'S' again and again will
change indicator in sequence of red -> green -> blue -> yellow from left to right on your unit. Each color
indicator represents one channel. Suppose you choose the blue indicated channel on receiver, rotate the roller
on the transmitter, the receiver will response by beep and the blue indicator on transmitter flashes, this indicate
the paring job is done. Just following the same steps to pair other transmitters. You need change to other
channel in case you find the indicator light is weak while paring, as this means the channel is already paired to
some transmitter. Or you may choose to erase the saved setting for this channel then pair to a new receiver.
Please refer to the below instruction for how to erase the paired code.
9 Erase the paired code
To erase the paired code in the receiver, press the 'S' key in standby mode, select LED indicator to choose the
channel you need erase, then press 'S' key till the light change to high light from low light.
10 Erase all the paired code in the receiver
To erase all the paired code in the receiver, press 'S' key and do not release till the 4 LED indicator flash at the
same time, then release the key. All the paired codes will be erased.
11 On working
In standby mode, the receiver will alarm in selected mode, in case transmitter start alarm. You will see the light
indicator flashes; the indicator on the right side of the receiver will be turned ON in case same transmitter send
signal repeat in 3 times. In case transmitter stop sending alert signal after some period of time, the receiver will
stop sound or vibration alert, the LED indicator will stop flashing then maintain ON status, this means the paried
transmitter just sent alert signal; in case no more alert signal, the receiver will enter standby mode after 10
seconds, the LED indicator will on work for another 10 seconds.
12 Low battery detection / low battery alert
The unit will auto detect the battery voltage in standby mode, in case battery voltage is lower than setting, the
buzzer will 'DiDDi' alarm, you should replace the battery imediately to ensure the unit works normally. In case
battery is not replaced in time, the unit will beep at intervals of 1 minute till battery is replaced.
13 Power OFF
Slid power key to 'OFF' to turn off the unit.
Notice
1 The max. battery voltage should no more than 5V, otherwise, may have the internal electronics parts damaged.
2 Each main unit/receiver only work and response to paired transmitter(s).
3 To save energy, the main unit should be powered off in case no usage. The battery should be taken out in case
long time no use.
4 To ensure good performance, please make use of good quality battery.
