OPERATION MANUAL – ALARMS
Specifications
1 Battery Type: R03P/AAA
2 Battery voltage: 1.5V*2
3 Standby current: 0.040mA
4 Working Current: 100mA
5 Wireless transmition type: AM
6 Radio transmitter operating frequency: 433MHz
How to use
1 Power ON self test
The unit will sound as DiDi on loading battery.
2 Switch on the unit
Hold press 'V' key for 3" to switch on the unit, the 3 groups LED indicators will flash thrice and speaker will sound
thrice. Then the unit will enter stand-by mode.
3 Adjust the volume
In standby mode, press 'V' key to adjust the volume, there are 6 levels including mute.
4 Select the tone
In standby mode, press T key to set sound tone. There are 7cycle optional tones for choice.
5 Senstivity adjustment
To change the senstivity of the unit, press S key. There are 4 levels for choice, initial setting is max. level. The unit
will be triggered in case the fishing line move 3.5mm distance in case the senstivity level is set as max. level. The
speaker will beep once to indicate the sensitivity is set as level 1; beep twice as level 2 and so on.
6 Casting or winding fishing line identification
The unit is able to indentify the fishing line is casting or winding. There are 7 cycle optional tones for choice for
casting the fishing line, and only 1 tone for winding the fishing line.
7 Night Light
In standby mode, hold press 'T' key for 1.5" will start night light. The LED under the roller will light up; hold press 'T'
key for 1" to turn it OFF.
8 Low battery detection / low battery alert
The unit will auto detect the battery voltage in standby mode, in case battery voltage is lower than setting, the
speaker will generate "DiDi" sound, you should replace the battery imediately to ensure the unit works normally.
In case battery is not replaced in time, the unit will beep at intervals of 1 minute till battery is replaced.
9 On working
In standby mode, roll the roller will trigger on the speaker and the LED indicator. In case fish line is move forwarde,
the LEDs on the left side and down side of the roller flash; in case fish line is move backward, the LEDs on the right
side and down side of the roller flash, the unit transmits alert signal to receiver. In case the roller stop rolling, the
speaker and signal transmition will stop, the LED stop flashing and keep light on then switch off after another 15".
10 Power OFF
Press 'V' key for 1.5" to turn OFF the unit. The 3 groups LED indicators will flash once and there will be DiDiDi sound.
Notice
1 The max. battery voltage should no more than 5V, otherwise, may have the internal electronics parts damaged.
2 Each main unit/receiver only work and response to paired transmitter(s).
3 To save energy, the main unit should be powered off in case no usage. The battery should be taken out in case
long time no use.
4 To ensure good performance, please make use of good quality battery.
OPERATION MANUAL – RECEIVER
Specifications
1 Battery Type: R03P/AAA
2 Battery voltage: 1.5V*2
3 Power off current consumption: 0mA
4 Working Current: 100mA
5 Wireless transmition type: AM
6 Radio transmitter operating frequency: 433MHz
