Summary: Behaviour With Various Cell Voltages; Overview: Fault Display Via Status Light; Technical Data - Conrad Voltcraft Li-Po Balancer 1007 Notice D'emploi

Summary: Behaviour with various cell voltages

Smaller than 1V
Smaller than 2.6V
Smaller than 2.7V
Smaller than 3.0V
Between 3.0 and 4.22V
Bigger than 4.22V
Bigger than 4.24V

Overview: Fault display via status light

Double flashing, pause, etc. Error on the sense line/plug assignment or cell faulty
Flashing quickly

Technical data

This balancer is used exclusively to equalise voltage differences of single cells within lithium polymer
battery packs during the charging or discharging procedure or without connected charger. The battery
packs may consist of at least two and a maximum of seven cells.
Input voltage
Max. permissible charging current
Cell balancing current
Overload protection/cell
Overload protection/cell
Charging end voltage/cell
Precision of balancing
Accumulator type
Status display
Display of balancing
Sense line connection
Dimensions (LxWxH)
Cell is not identified, as deep discharged or defect.
Switching to standby mode due to deep discharge protection.
If not connected to charger, standby mode after 15 seconds.
Cell is not discharged further.
Balancing possible.
Connection to charger is temporarily ended until all cells are equalised
at a lower level.
Connection to the charger ended, switch to standby mode.
Overvoltage or undervoltage, voltage loss via charge lines too big
5.3 -29.7 V/DC
10 A
70 mA
4.24 V (±0.01 V)
2.6 V (±0.01 V)
4.22 V (±0.01 V)
better 10mV/cell, typical 5mV/cell
Lithium Polymer, 2 - 7 cells
via light-emitting diodes
Every cell separately
Type JST-EH system, max. 8-pin
approx. 120 x 80 x 24 mm
