Operating Instructions
Electrical Data
Rated cross-section
Quantity of terminal points
Switching elements
Service life
electrical/mechanical
Contact material
Contact version
Rated isolation voltage
Short-circuit protection
Mechanical life
Electrical life
Conventional thermal
current
Utilization categories
Switching capacity according to EN 61058-1 –
Rated operating current I
Alternating current 40 Hz to 80 Hz
Ohmic load
Load U
I/AC-12 A
125 V
5 A
250 V
4 A
400 V
2 A
Direct current
Last U
Ohmic load
30 V
7 A
250 V
0.6 A
The MODEX control component can be used in the ranges of
temperature classes T4 to T5. The component's flameproof
encapsulation is designed for resistance to temperatures from -40 °C
to +100 °C.
The rated voltage, rated current and in the case of switching devices
the utilisation category depend on the respective installed
components and are determined by the manufacturer.
BARTEC GmbH
Max-Eyth-Straße 16
EN
97980 Bad Mergentheim
Germany
Control units MODEX
(Translation)
Isolator terminal IP30, type 07-7331-6131/EE00
max. 2.5 mm
2
4
2-pole positive opening contact
0.6 ≥ 10
switching cycles
4
Pure silver, gold plated
positive opening contact
400 V
Fuse-links
characteristic quick-acting: 10 A
1 x 10
switching cycles
6
1 x 10
switching cycles
4
≤ +40 °C
7 A at T
a
AC-15 for 400 V / 2 A
DC-13 for 250 V / 0,15 A
Inductive load
I/AC-15 A
4.0 A
2.0 A
Inductive load
4 A
0.15 A
Phone: +49 7931 597-0
Fax: +49 7931 597-119
Produkt marking
5. Transport and Storage
ATTENTION
Damage due to incorrect storage!
Adhere to storage and transport temperatures.
Condensation can form on the components in a cold
environment.
Use the original packaging for transport/storage.
6. Assembly
WARNING
Danger in the event of incorrect procedures!
Assembly location outside the potentially explosive atmosphere
in the enclosure with at least IP20 or closed switchgear.
Assembly, disassembly, installation and commissioning work
may be done only by qualified personnel who are authorised
and trained to assemble electric components in hazardous
areas.
The relevant installation and operating regulations, such as
e.g. Directive 1999/92/EC, Directive 94/9/EC, BetrSichV (the
German industrial health and safety ordinance), EN/IEC
60079-14, the DIN VDE 0100 series and other applicable
national standards or ordinances, must be observed when
setting up or operating explosion-proof electric systems.
info@bartec.de
Reservation Technical data subject to change without notice.
www.bartec-group.com
(from drawing 01-7311-7J0005)
Changes, errors and misprints may not be used
as a basis for any claim for damages.
3/6
