UNFIX 800 EGF MOUNTING (CONTINUATION)
• Attach the previously assembled crossbars to the feet. Do not tighten theme completely.
• UNIFIX 800 EGF is adaptable to all types of panels.
To pre-adjust, measure the center distances of your panel's mounting points to pre-set distance
N°2.
If you are using your UNIFIX 800 EGF bracket in a meadow or lawn, distance N°3 must be adjusted
so that any vegetation does not cover the lower part of the solar panel.
27
D8
M8x20
X16
X16
www.uniteck.fr
M8
X16
EN
