STEP 1 HANGING THE DOOR PANEL
Required Tools
• Cross-head screwdriver
• Hex key
Loosen all the side screws on the glass door, but do
not remove them. Side brackets on door panel will
slide into these screws.
NOTE: Picture shows top hanging bracket location
relative to glass door and door panel. The bracket is
actually behind door panel.
Hold the door panel at an angle from the top of the
glass door and lower the screw holes of the top
hanging bracket onto the adjustment screws on top of
the glass door.
31-1000764 Rev. 0
Door Panel Installation
• Spanner
Align the door panel straight with the glass door and
slide-in the side brackets to the side screws of the
glass door.
Tighten the side screws loosely to temporarily secure
the door panel.
Screw the M8 washer and nut to the adjustment screw
and loosely tighten.
31
