ATTACHING THE SHORT GLASS TRIMS
1
Place the short trim along the length of the top of door
panel cutout across the top ends of the long trims.
2
Short edge
Long edge
Cut both ends of the short trim to length.
Peel off a small portion of red protective film from the
short edge.
REQUIRED: CONNECTING TO POWER SUPPLY
At the back of your appliance, connect the power plug to the power outlet (115VAC, 60Hz).
• You will hear a chime sound when the appliance is powered on.
When powered on for the first time, your appliance will default to Install mode.
ZONE ZONE
SELECT SELECT
HOLD 3 SEC OLD 3 SE
TO UNLOCK
31-1000764 Rev. 0
Door Panel Preparation
RED
UPPER CELLAR
WINE
MODE
LOWER WHITE
SPARKLING
3
Long trim
Attach the peeled portion starting from one end of flange
perpendicular to top end of long trim.
4
Short trim
Continue attaching the short trim for the length of the top
of door panel cutout, peeling off the film as you go.
Ensure the trim is aligned flush to inside edge of flange.
Attach the remaining peeled portion of short trim to the
flange perpendicular to top end of the other long trim.
Repeat steps 1–4 to the bottom of door panel cutout.
Once installation is complete, activate the appliance
by pressing ZONE SELECT on the control panel for 4
seconds to start cooling. NOTE: If this is not done, the
unit will not cool.
• Refer to your 'Owner's Manual' for more information on
activating your appliance.
27
Short trim
Long trim
