SAFETY INSTRUCTIONS
f. Do not face the battery when making the final connection.
g. When disconnecting the charger, always do so in reverse sequence of the connecting procedure.
Also break the first connection while as far away from the battery as physically possible.
The supply cord cannot be replaced. If the cord is damaged the appliance should be safely disposed.
Examine the battery charger regularly for damage, especially the cord, plug and enclosure.
If the battery charger is damaged, it must not be used until it has been repaired.
TECHNICAL SPECIFICATIONS
Product Name
Model
Nominal AC Input Voltage
Nominal AC Input Frequency
Output
Product Size
Charging Battery Type
LED Indicators
Activate Function
Full Cut-off Voltage
Cooling Type
Ingress Protection
Circuit Protection
Nominal Working Temperature
Relative Humidity
Introduction
The onboard marine
LiFePO4
batteries. This charger offers users extended battery life and reliability with its built-in protection features. By using this charger, users
can get the quickest, most intelligent, efficient charge and experience longer run times and shorter charge times for the battery.
It features small volume, high stability, and high security.
Features
• IP67 Rating.
• Can Charge 4 Batteries at the same time.
• Marine-grade construction.
• Aluminium Stretched Plate and Waterproof Cooling Fan at the Bottom of Product for Good Heat Dissipation.
• LED Indicators for Battery Charging Percentage.
• Fast Charging with 10A for Each Bank.
• Wake Up Function for Low Voltage of Lithium Battery.
• Automatic Small Current Charge after 24 Hours of Fully Charged for LiFePO4 Battery.
• Short-circuit Protection.
• Reverse Connection Protection.
• Overcharge Protection.
• Overtemp Protection.
(CONTINUED)
4-Bank Marine Charger with M8 Ring
EWC12-10x4
105-125V AC
60Hz
4x12 V/10 A
304 x 245 x 99 mm
Each bank has one Mode button to choose charging battery type:
12V LiFePO4, 12V Wet, 12V AGM
Power & Battery Type & Charging Status LED Indicators
Wake Up Function for Low Voltage of LiFePO4 Battery
(Press the mode button on the bank panel for 3-5 seconds to start this function)
14.1V-14.4V for 12V Lead Acid Battery & 14.4V-14.7V for 12V AGM / LiFePO4 Battery
Aluminium stretched plate and waterproof cooling fan at the bottom of product for
better heat dissipation
Filled with pure epoxy resin for IP67 protection
Short-circuit Protection & Reverse Connection Protection
& Overcharge Protection & Overtemp Protection
25°C
5%~95%
/Lead acid/AGM battery charger is specifically designed to charge your 12V LiFePO4/Lead acid/AGM
EWC12-10X4
USER'S MANUAL
