3 Operation and indication components
3.1 Overview Display
Pos. in Description
Fig. 1
1 State of charge Battery
(max. 10 bars, 1 bar
corresponds 10 %)
2 State of charge range
extender (max. 5 bars,
1 bar corresponds 20 %)
3 Display panel for
different screen views
with riding informa-
tion (see section 6 auf
Seite 9)
4 Assist mode
(OFF,
5 Button
3.2 Overview Remote
Pos. in Description
Fig. 2
1 UP Button
2 DOWN Button
Fig. 1:
)
Fig. 2:
4
1
Operation and indicaton
components on Display
2
Operation on the Remote
2
3
5
1
EN – 7
