Outdoor Remote Sensor (Transmitter) Features

TX LED
EN
Sensor detection port
1. Battery Compartment: Holds 2 X AAA batteries to power the unit.
2. Rain-proof and wall-mounted
3. Outdoor Temperature range: -58° ~158°F (-50°C~70°C).
4. Humidity range: 10% ~ 99%.
Buttons
CHANNEL Selector (1,2,3): Slide to set Channel 1,2 or 3.
RESET: Press once to reset the remote sensor.
TX: Press to send temperature/humidity data to the receiver manually.
Wall hanging hole
RESET
TX
2*AAA battery
design.
-9-

Battery Installation and Setup

1. Open the battery compartment of the remote sensor as below Figure;
Channel 1.2.3
2. Slide the channel selector switch inside the battery
to your desired channel. For the first remote you may select any
channel, for additional remotes select any unused channel;
3. Insert (2) AAA batteries according to the polarity markings. Replace
the battery compartment cover;
4. Open the battery compartment at the back of the base
insert (2) AAA batteries according to the polarity markings. Replace
the compartment door;
5. Press the °F /°C button at the back of the base station to display
the temperature in °F or °C.
compartment
station and
-10-
