DESCRIPTION
1. Steam head
2. Integrated hanger
3. Trouser clips*
4. Steam head hook
5. Hanger holder
6. Hanger fastening screw
7. Pole locking clips
8. Telescopic pole
9. Steam hose
10. Electrical cord hook
11. Electrical cord
12. Transport handle
13. Water tank handle
14. Removable water tank
15. Control panel
16. Stability leg (x2)
17. Pole fastening screw
18. Base unlocking button
BEFORE USE
1 • Garment steamer assembly
Pole assembly
1. Pull and rotate the 2 stability legs until you hear a "click" sound.
2. Unscrew the pole's fastening screw on the base of the pole.
3. Hold the pole such that the electrical cord hook is at the back. Check that the 2 pole clips
are unlocked. (fig. 3)
4. Insert the pole into the base by pressing downwards until the holes of the pole and base are
at the same level, so that you can put the screw back. If the holes are not aligned, check that
the clips of the pole are well and truly unlocked.
5. Screw the pole fastening screw back in as far as it will go so that the pole is firmly fixed to
the base.
6. Adjust the pole to its maximum height by sliding it upwards. Make sure the 3 segments of
the pole are fully extended then lock the 2 clips.
Integrated Hanger assembly
1. Unscrew the hanger fastening screw at the bottom of the hanger.
2. Hold the hanger such that the hanger holder is on the same side as the appliance control
panel.
3. Insert vertically the hanger on the top of the pole. The holes at the bottom of the hanger
and in the pole should be at the same level.
4. Put the screw back and screw in as far as it will go so that the hanger is firmly fixed to the
pole.
5. Install the steam head on top of the integrated hanger.
* depending on model
All manuals and user guides at all-guidesbox.com
19. ON/OFF switch
20. Appliance
21. "Anti calc" cap
22. Base
23. Press & Steam vertical support*
24. Press & Steam pouch*
25. Press & Steam locking handle*
26. Press & Steam locking hook*
27. Glove*
28. Fabric brush*
29. Lint pad*
30. Crease attachment*
31. Variable steam settings*
32. "Anti calc" indicator*
33. Empty tank indicator*
34. Steam ready indicator / auto off indicator
35. Variable steam setting button*
36. Steam level indicator*
(fig. 4)
(fig 6)
(fig. 5)
(fig. 1)
