6 Calibration Camera Alignment
6.1 Take away the fixed focus card, click on the "Camera
Alignment" window, if this interface is closed, please click
"Camera Control" -> "Camera Alignment" -> "Camera" ->
Next
6.3 Click Frame to see if there is a collision, if there is a
collision, you need to set a smaller Scale value, or recalibrate
the camera
6.2 Set the engraving parameters (refer to the laser parameter table),
and set the Scale value according to the actual positioning size, see
the table below
6.4 Click Start and make a positioning mark
7
Size
Scale
mm^2
100 200*200
150 300*300
200 400*400
