STEP 4
Insert large cam locks (2) into back bottom panel (G) as shown below.
Insert large wood dowel (3) and barrel nut (7) into the left / right side panel as shown.
Attach bottom panel (H) to the back bottom panel (G) and secure by rotating the large cam
locks (2) 1/2 turn clockwise using a Phillips head screwdriver (not included).
Attach bottom panel (H) to left / right side panel (B&C) with bolts (10), Use the Allen key (12)
to tighten the bolts.
B
All manuals and user guides at all-guides.com
3-Drawer Dresser
DL8876-1, DL8876-1WN
C
2
7
2
3
7
3
10
7
3
7
3
H
10
10
2
3
7
10
10
2 PCS
4 PCS
4 PCS
4 PCS
