INSTALLATIoN
Installation
f Fit the dummy cover by pushing it in on both sides until all 4 f
locking tabs click into place. When engaging the locking tabs,
apply counter-pressure by pushing against the appliance
cover from the inside.
WARNING Electrocution
All 4 locking tabs on the dummy cover must click into
place. The locking tabs must be complete and undam-
aged. If the dummy cover is not inserted correctly, user
protection against contact with live components is not
guaranteed.
24 | FFB Set
All manuals and user guides at all-guides.com
6.2
f Guide the cables over the edge of the flush box. f
f Place the flush mounted power supply unit in the flush box. f
f Connect the flush mounted power supply unit to the cable f
f Push all terminals into the flush box. f
FFB W Set and FFB W Plus Set EU – installation
with cover frame
(terminals included with standard delivery).
