SCHEDA INTERRUTTORE CREPUSCOLARE-TEMPORIZZATO
CREPUSCULAR-TIMED SWITCH BOARD
CARTE INTERRUPTEUR CREPUSCULAIRE-TEMPORISE
TARJETA INTERRUPTOR CREPUSCULAR-TEMPORIZADO
KARTE GETAKTETER DÄMMERUNGSSCHALTER
JA338
ISTRUZIONI PER L'USO – NORME DI INSTALLAZIONE
USE AND INSTALLATION INSTRUCTIONS
INSTRUCTIONS POUR L'EMPLOI – NORMES D'INSTALLATION
INSTRUCCIONES PARA EL USO – NORMAS DE INSTALACIÓN
BETRIEBSANLEITUNG - INSTALLATIONSVORSCHRIFTEN
Publicité
Manuels Connexes pour Genius JA338
Sommaire des Matières pour Genius JA338
- Page 1 SCHEDA INTERRUTTORE CREPUSCOLARE-TEMPORIZZATO CREPUSCULAR-TIMED SWITCH BOARD CARTE INTERRUPTEUR CREPUSCULAIRE-TEMPORISE TARJETA INTERRUPTOR CREPUSCULAR-TEMPORIZADO KARTE GETAKTETER DÄMMERUNGSSCHALTER JA338 ISTRUZIONI PER L’USO – NORME DI INSTALLAZIONE USE AND INSTALLATION INSTRUCTIONS INSTRUCTIONS POUR L’EMPLOI – NORMES D’INSTALLATION INSTRUCCIONES PARA EL USO – NORMAS DE INSTALACIÓN...
- Page 2 Una errata installazione o un errato uso del 9 ) GENIUS is not responsible for failure to observe Good Technique in the prodotto può portare a gravi danni alle persone. construction of the closing elements to be motorised, or for any 2 ) Leggere attentamente le istruzioni prima di iniziare l’installazione del...
- Page 3 ENGLISH CREPUSCULAR-TIMED SWITCH BOARD INSTRUCTIONS FOR USE - DIRECTIONS FOR INSTALLATION GENERAL FEATURES This crepuscular-timed switch board serves to control outside service lights. Four operating modes and a choice of time settings enable you to control night lighting in a different way. TECHNICAL SPECIFICATIONS Hardware specifications Power supply...
- Page 4 ENGLISH CONTROL BOARD CONNECTION Before attempting any work on the control board (connections, programming, maintenance), always turn off power. Important: High voltage could be present when disconnecting the J2 terminal board. Observe points 10, 11, 12, 13 and 14 of the GENERAL SAFETY OBLIGATIONS. Always separate power cables from control and safety cables (push-button receiver, photocells, etc.).
- Page 5 ENGLISH PROGRAMMING The board can operate in 4 different modes: Crepuscular mode Timed mode with crepuscular control Timed mode Bistable mode Crepuscular mode In this mode, the relay which is actually the board output is controlled strictly by the crepuscular sensor. When incident light on the photo-transistor falls beneath the threshold set with the TR1 trimmer, the LD1 red LED lights up;...
- Page 6 “16”. mente abierta. 1 8 ) GENIUS décline toute responsabilité quant à la sécurité et au bon 2 5 ) El usuario no debe por ningún motivo intentar reparar o modificar el fonctionnement de l'automatisme si les composants utilisés dans producto, debe siempre dirigirse a personal cualificado.
- Page 7 BERGAMO - ITALIA BERGAMO - ITALIEN The descriptions and illustrations contained in the present manual are not binding. GENIUS reserves the right, whils leaving the main features El equipo electrónico das elektronisch Gerät of the equipments unaltered, to undertake any modifications to holds Declara que: erklärt:...
