ADJUST THE ISOFIX CLAMPING HEAD
3
The ISOFIX connector can be extended to fit different positions of the ISOFIX
on the car seat.As shown in Figure 1,pull up the adjusting button on the front
of the seat,and the ISOFIX connectors on both sides are ejected to the longest
position of the ISOFIX.Clip the ISOFIX connector into the ISOFIX interface
inside the car.Hearing "click" indicates the FIX collet is fully locked with the
ISOFIX interface,and the ISOFIX lock window is green(as shown in Figure
2).To release the ISOFIX connector ,press the FIX connector in the diagram
and release the push button.After the installation is completed, according to
the position of the seat, pull the adjustment button, and push back the child
safety seat until tight,the ISOFIX base is installed at this time.
IMPORTANT:You can draw back the ISOFIX connector directly ,except the
longest position .You must reléase
EN
ISOFIX adjusting
button
All manuals and user guides at all-guides.com
2
1
Maximum position
Minimum position
