CONTROL PANEL FEATURES

RPM
POWER
33 45
1. Audio Level Control:
adjusts the volume of the onboard speaker,
headphone and line out outputs.
NOTE: Make sure the Audio Level Control is
set to OFF when connecting any alternate
audio output devices.
2. Tone Control:
adjust the low and high frequency audio
levels.

BATTERY INSTALLATION

PITCH
TONE AUDIO
78
-10% +10% LOW HIGH OFF
This rotary control
This feature allows you to
This product can be powered by 6 "D" Cell batteries. They should be loaded as
shown to the left, with the positive end toward the handle.
3. Pitch Control: This knob adjusts the pitch of the
music +/- 10%. In the center position the pitch is at
0%.
4. RPM Selection Switch:
RPM of the turntable platter -- 33, 45, and 78 RPM.
Please select the appropriate setting for the record
you are playing; if the music comes out at a strange
or unusual pitch, this may indicate that the wrong
RPM setting is selected
5. Power LED: This LED remains lit while the unit is
powered on. To avoid wasting battery power, make
sure the power is off when storing or transporting
the unit.
3
This switch selects the
