1. STOP SWITCH - "Toggle Switch" mounted on top of Throttle Trigger Housing. Move switch Forward to Run, Back
to Stop.
2. THROTTLE TRIGGER - Spring loaded to return to idle when released. When accelerating, pull trigger gradually for
best operating technique. DO NOT hold trigger when starting.
3. MUFFLER/SPARK ARRESTOR - The muffler controls the exhaust noise while the spark arrestor prevent hot,
glowing particles of carbon from leaving the muffler where they could possibly start a fire.
4. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then pull quickly and firmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
5. FUEL TANK - Contains fuel and fuel filter.
6. FUEL TANK CAP - Cover and seals fuel tank opening.
7. PRIMER BULB - Pumping primer bulb before starting engine draws fresh fuel from the fuel tank priming the
carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
8. AIR CLEANER - Contains replaceable filter element.
9. CHOKE - The choke control is located on the side of the air filter case. Move choke to "COLD START" to close the
choke for cold starting. Move choke to "RUN" position to open choke.
10. GEAR BOX - Houses gears for driving tines.
11. TINES - Used to till or cultivate soil. Removable for cleaning.
12. CARRYING HANDLE - Use for convenient transportation.
13. TINE GUARD - Used to help deflect debris away from operator and reduce accidental contact of tines.
14. SAFETY DECAL - See Description on Page 4.
15. SAFETY DECAL - See Description on Page 4.
