A+R KATE 60-IN BATHTUB
INSTALLATION MANUAL
GUIDE D'INSTALLATION
ALLEN + ROTH and logo design are trademarks or registered trademarks of LF, LLC. All
MANUAL DE INSTALACIÓN
Rights Reserved
ALLEN + ROTH et son logo sont des marques commerciales ou des marques déposées de
LF, LLC. Tous droits réservés
ITEM #/ARTICLE #/ARTÍCULO #:3637597
ALLEN + ROTH y el diseño del logo son marcas comerciales o marcas registradas de LF,
MODEL#/MODÈLE#/MODELO #:KATE
LLC. Todos los derechos reservados
An installation video guide can be found on our Youtube channel:
Un guide d'installation video est disponible sur notre chaîne Youtube:
Una guía de instalación de vídeo está disponible en nuestro canal de Youtube:
http://youtu.be/EmpHvs4Y-ko
Questions, problems, need help?
Call our customer service department at
1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
You could also contact us at partsplus@lowes.com or visit www.lowespartsplus.com.
English and French speaking representatives available
Vous avez des questions, des problèmes ou besoin d'aide?
Communiquez avec notre service à la clientèle au
1-866-439-9800, entre 8 h et 20 h (HNE), du lundi au dimanche. Des représentants
Vous pouvez aussi nous contacter à partsplus@lowes.com ou sur www.lowespartsplus.com.
anglophones et francophones sont disponibles.
¿Preguntas, problemas, necesita ayuda?
Llame a nuestro Departamento de Servicio al Cliente al
1-866-439-9800, de lunes a domingo de 8 a.m. a 8 p.m., hora estándar del Este, de lunes a domingo.
También puede contactarnos en partsplus@lowes.com o para www.lowespartsplus.com.
Representantes que hablan inglés y francés disponibles.
P. 1
SM20683
Publicité
Sommaire des Matières pour LF Allen + Roth KATE 3637597
- Page 1 ALLEN + ROTH et son logo sont des marques commerciales ou des marques déposées de LF, LLC. Tous droits réservés ITEM #/ARTICLE #/ARTÍCULO #:3637597 ALLEN + ROTH y el diseño del logo son marcas comerciales o marcas registradas de LF, MODEL#/MODÈLE#/MODELO #:KATE LLC. Todos los derechos reservados An installation video guide can be found on our Youtube channel: Un guide d’installation video est disponible sur notre chaîne Youtube:...
- Page 2 SPECIFICATION SPÉCIFICATIONS ESPECIFICACIONES Drain / Drenaje ø2” [ø50] 40 7/8” [1038] 57 1/4” [1454] 60” [1524] Overflow / Trop-plein / Desborde 47.6gal 55lbs 0.18m 25kg Measures: inch [millimeter] Mesures: pouce [millimètre] Medidas: pulgadas [milímetros] P. 2...
- Page 3 FLOOR TRACING TEMPLATE GUIDE DE TRAÇAGE GUÍA DE SEGUIMIENTO Rough-in zone for water supply pipes Floor cut-out for P-trap Zone indiquée pour tuyaux d’entrée d’eau Ouverture dans le plancher pour p-trap Zona de empotramiento para tuberías de entrada de agua Abertura en el piso para trampa en P Drain Rough-in zone for waste pipe...
- Page 4 PART LIST LISTE DES PIÈCES LISTA DE PIEZAS PART # DESCRIPTION QUANTITY CODE # DE PIÈCE DESCRIPTION QUANTITÉ CODE PIEZA# DESCRIPCIÓN CANTIDAD CÓDIGO OVE FLEX-H2 flexible pipe OVE FLEX-H2 tube flexible OVE FLEX-H2 tubo flexible OVE FLEX-P flexible P-trap (NOT SUPPLIED) Available upon request.
- Page 5 CAUTION ATTENTION ATENCIÓN You will need at least two people to install this product properly. In order to reduce the risks of personal injuries, do not support or lift the bathtub by the rim. Provide adequate support under the feet. The distributor is not responsible for any damage to the unit or personal property caused by improper installation.
- Page 6 FLOOR TRACING TRAÇAGE SEGUIMIENTO 1.1. Use the floor tracing template supplied in this manual to trace the proper position of your supply pipes, your drain and your P-Trap rough-in. 1.2. Place the bathtub in the desired position on the floor, manually locate the proper position for your plumbing and trace the outline on the floor. 1.3.
- Page 7 FAUCET INSTALLATION ON THE BATHTUB (OPTIONAL) INSTALLATION DU ROBINET SUR LA BAIGNOIRE (OPTIONNEL) INSTALACIÓN DEL GRIFO EN LA BAÑERA (OPCIONAL) 2.1. Locate where you will drill the holes into the acrylic, and stick masking tape onto that area. This will prevent the acrylic from chipping. 2.2.
- Page 8 INSTALLATION OPTION #1: USING OVE FLEX-H2 INSTALLATION OPTION #1: UTILISATION DU OVE FLEX-H2 OPCIÓN DE INSTALACIÓN #1: USO DEL OVE FLEX-H2 3.1. Install the OVE FLEX-H2 flexible pipe by screwing it to the preinstalled bathtub drain outlet. Use teflon tape and/or thread sealant. 3.2.
- Page 9 INSTALLATION OPTION #2: USING THE OVE FLEX-P INSTALLATION OPTION #2: UTILISATION DU OVE FLEX-P OPCIÓN DE INSTALACIÓN #2: USO DEL OVE FLEX-P 4.1. Install the OVE LEX-P flexible P-Trap by screwing it to the preinstalled bathtub drain outlet. Use teflon tape and/or thread sealant. Then, as shown in the illustration, connect the P-Trap to the Flexible Tube.
- Page 10 INSTALLATION OPTION #3: USING REGULAR PVC PIPING INSTALLATION OPTION #3: UTILISATION DE TUYAU PVC RÉGULIER OPCIÓN DE INSTALACIÓN #3: USO DE TUBERÍAS DE PVC COMUNES 5.1. Apply Teflon Tape and/or thread sealant to the pre-installed bathtub drain. 5.2. Screw the provided 1-1/2 NPSM to SCH40 Pipe Adapter to the drain. Cut a 1-1/2 PVC Extension Tube to the desired length. Then connect it to the Adapter using PVC pipe sealant to join the parts together.
- Page 11 SEALING SCELLAGE SELLADO BEFORE FIXING YOUR TUB TO THE FLOOR, ENSURE THAT YOU HAVE INSTALLED YOUR FAUCET (if applicable) AND THAT YOU HAVE CHECKED FOR LEAKS. 6.1. Test for leak by filling up the tub and let it drain. Then check all plumbing connections for leaks. 6.2.
- Page 12 CONSUMER RESPONSIBILITIES The DISTRIBUTOR’s products will remain beautiful for many years if properly cared for. The DISTRIBUTOR does not recommend the use of harsh abrasive cleansers on any of its products. Harsh cleansers will damage the finish of your product. MAINTENANCE ▶...
