Possible Uses - SKALT Prostop 6 SE Mode D'emploi

Article 4.4 Static strength (EN 364: 1993)
12 kN held for 3 minutes without release (wire rope) (PASS).
15 kN for 3 minutes without release (Webbing) (PASS).
Article 4.5 Dynamic Performance (EN 364: 1993)
When tested with the test mass of 100 kg,
The stop impact <6.00 kN, stop distance <2.00 mtr. (PASS).
Article 4.6 Corrosion resistance (EN364: 1993)
Corrosion test in accordance with ISO 9227: 1990-24 hours (PASS).
AS PER VG11 RFU # 11,060 Result/Comment
1. Dynamic performance: 100 kg mass
a. Perpendicular to the edge: Breaking force <_ 6 kN
b. Lateral movement of 1.5 m: Breaking distance less than 2 m
2. Dynamic strength
a. Perpendicular to the edge: 100 kg mass held
b. Lateral offset of 1.5 mtr: 100 kg mass held
3. Static strength after each dynamic
strength test f = 3 kN (rope) 4.5 kN (webbing) 3 mints

POSSIBLE USES:

The fall arrest block can be used as part of a fall protection system or as part of a
safety system. When used as part of the fall protection system, a suitable anchor
point (preferably above the user's head, at least 12kN) must be used. connections to
the anchor points and other equipment must be made using carabiners according to
EN362. Specifically, the equipment must be used in both normal and horizontal
conditions
Material of the cable
- for steel cable block - 4.8 mm Galvanized steel wire. - for webbing block - 25 mm
polyester textile strap.
