MSA Evolution 5600 Manuel De Prise En Main Rapide

All manuals and user guides at all-guides.com
Quick Start Guide
EVOLUTION
Thermal Imaging Camera
The quick start guide does not replace the operating
manual. It is imperative that the operating manual be
read and observed when using the thermal imaging
camera. In particular, the safety instructions, as well as
the information for the use and operation of the
apparatus, must be carefully read and observed.
The operating manual can also be provided as a hard
copy upon request.
4
3
2
1
A Front view of the camera
B On-screen indicators
1 Battery compartment lock
2 Camera handle
3 ON / OFF button
4 Display
5 Shutter indicator
GB
®
5600
A
5
6
7
8
6 Target point of the temperature
indicator
7 Low sensitivity mode "L"
8 Over temperature Indicator
9 System status
10 Battery status indicators
11 Numerical temperature indicator
12 Graphic temperature indicator
B
12
11
9 10
Order No.: 10084447/00
