MJ71 Blades

725-BLD7-FL
5
6
8
4
Item Part No. Description
1 BLD-25025-AC BLADE 250xDia 25 (Anti-Clk)
2 BLDB6-315-25 BLADE BACK (315 CTR 25 deg)
3 DF-BMP J205 G/BOX BLADE MOUNT
4 BS-2507-03 THREADED BLADE SUPPORT
5 1/2F 1/2" FINE NYLOC NUT
6 12x112FSKS 1/2"x1 1/2" FINE SOCKET HEAD 12.9
7 CW39174 DISC SPRING 39x17x4 (YELLOW)
8 FW1-7 DIA 1" THIN FLAT WASHER
9 M10 M10 NYLOC NUT
10 M10x30SKBH M10x30 SOCKET BUTTON HEAD 10.9
11 M16 M16 NYLOC NUT
2 off MJ71-190
2 off MJ71-240
2 off MJ71-340
3 off MJ71-400
4 off MJ71-540
5 off MJ71-600
5 off MJ71-730
62
3
11
7
9
1
10
Qty
2
1
1
2
4
4
2
2
2
2
2
optional
optional
