1 - Pot 10K input A2
2 - Selector SW1 input A2 : internal pot 10K / external pot
3 - Input pot A2
4 - Jumper JP3, JP4 selection input A0 - A1 - 5/10VDC
5 - Input A1- A0 5/10V DC
6 - Arduino placement
7 - Input D12 - D13 5/24V DC
8 - Jumper JP1, JP2 selection input D12 - D13 - 5/24VDC
9 - Cut for separate power motor
10 - Power supply input 12/ 24V DC
11 - I2C output
12 - Jumper JP6 selection power supply arduino : 9V / USB
13 - Fus 1 amp + OUT
14 - RX-TX output
15 - Output MOTOR 600 mA
4
4
5
1 2
3
9
10
11 12
www.cebek.com
6
14
13
-
sat@cebek.com
7
8
15
AT-03
