2 - INTRODUCING THE PRODUCT

2.1 - Description of the product

The POWERFUL gear motors are destined to be installed in
systems for the automation of gates with hinged doors.
The POWERFUL gear motors have been designed and constructed
2.2 - Model and technical characteristics
Code Description
PWF24 Gear motor for hinged doors with max length 2,3 m and weight 250 Kg, 24 Vdc
TECHNICAL DATA
MODELS
Torque
Working cycle
Opening time at 90°
Control board
Power supply
Power supply
Absorption
Engine power
Integrated lights
Degree of protection
Dimensions (L - P - H)
Weight
Operating temperature
Leaves maximum weight

2.1 - Description of the control unit

The CT20224 control unit is the most modern, efficient system for
the control of Key Automation motors for the electric opening and
closure of swing gates.
All other, improper, use of the control unit is forbidden. The
CT20224 has a display allowing easy programming and constant

2.2 - Description of the connections

1. Motor power supply connections
2. Transformer power supply connections
3. 24Vdc and 24Vac output connections to controls and safety
devices
4. Connector for battery charger KBP
5. Connection of flashing light, courtesy light, gate open
indicator light/electric lock
6. Functions display
7. Safety device dip switch
to be fitted onto hinged doors within the weight limits indicated
in the technical specifications table. The use of gear motors for
applications which differ from those indicated above is prohibited.
Nm
Cycles/Hour
sec
Vac
Vdc
A
W
IP
mm
Kg
°C
Kg
monitoring of the input status; the menu structure also allows easy
setting of working times and operating modes.
8. Fuse 2AT slow-acting
9. STOP-PH2-PH1-OPEN-CLOSE-PAR-SBS safety led and led
input led
10. STEPPING SBS button
11. UP + button up
12. MENU button menu
13. DOWN - (DOWN) button down and radio menu
14. Antenna
15. KEY led
PWF24
120
60
14-20
CT20224
230
24
0,6
115
no
44
125 - 260 - 310
10,5
-20°+55°
250
