Functional principle

Screwing on a blind rivet nut
●
Ensuring it is straight, set the blind rivet nut against the threaded
mandrel A.
Keep switch K pressed until the tool stops; then release.
●
Hold the blind rivet nut during the entire screwing operation.
●
●
Repeat the procedure if the blind rivet nut does not rest against the nosepiece
B after the screw-on operation. Hold the blind rivet nut and briefly press the
switch K to start the screw-on operation. Now repeat the screw-on operation!
Setting a blind rivet nut
Insert the screwed-on blind rivet nut as far as it will go into the rivet
●
hole.
Press and hold switch K until the setting and automatic screw-on
●
procedure is finished
Changing the threaded mandrel (Fig. 3)
Unscrew nosepiece B.
●
Push back slide M as far as it will go.
●
Unscrew threaded mandrel A and change.
●
Align the surfaces of the hexagon on the screwed-in threaded
●
mandrel 1 with the sur- faces of the hexagon of the holder.
Lock the threaded mandrel A by pulling the slide M forward as far
●
as it will go.
Screw on matching nosepiece B, set threaded mandrel length x (see Point
●
2.7.1) and secure nosepiece B with lock nut C to prevent it turning.

2. QUICK CHARGER AND BATTERY

Technical data
Quick charger
Type:
Input voltage:
Output voltage: 18.0 V
Output current: 2.4 A max.
Weight:
Rechargeable Battery
Rated voltage: 18.0 V
Number of cells:
Type of cells:
Capacity:
Weight:
1 5000 003
220-240 V~ / 50-60 Hz
0.36 kg
5
Li-ion
2.0 Ah (or 4.0 Ah)
0.4 kg (or 0,6 kg)
